Moxa Technologies ioLogik E1212 User Manual

ioLogik E1200 Series Modbus/TCP Default Address Mappings
A-5
ioLogik E1212 Modbus Address and Register
Map
I/O
Parameter Name Description Start
Address
(decimal)
Point Type Start
Register
(decimal)
Length Access Type
DI_counterOverflowFl
ag
0: Normal, 1:
Overflow
1000 02:INPUT
STATUS
11001 16 R bit
DI_counterOverflowFl
agClear
1: clear
overflow flag
0288 01:COIL
STATUS
00289 16 R/W bit
DI_counterReset 1: reset to
initial value
0272 01:COIL
STATUS
00273 16 R/W bit
DI_counterStatus 0: STOP, 1:
START
0256 01:COIL
STATUS
00257 16 R/W bit
DI_counterValue high/low word 0016 04:INPUT
REGISTER
30017 32 R 2 words
DI_status 0: OFF, 1: ON 0000 02:INPUT
STATUS
10001 16 R bit
DI-all_statusFromDI-
00
0: OFF, 1: ON 0048 04:INPUT
REGISTER
30049 1 R word
DO_p2pSafeModeFla
gClear
1: clear safe
mode flag
4128 01:COIL
STATUS
04129 8 R/W bit
DO_p2pSafeModeFla
g
0: OFF, 1: ON 4112 02:INPUT
STATUS
14113 8 R bit
DO_p2pStatus 0: OFF, 1: ON 4096 02:INPUT
STATUS
14097 8 R bit
DO_pulseCount 0036 03:HOLDIN
G
REGISTER
40037 8 R/W word
DO_pulseOffWidth unit: 1 ms 0068 03:HOLDIN
G
REGISTER
40069 8 R/W word
DO_pulseOnWidth unit: 1 ms 0052 03:HOLDIN
G
REGISTER
40053 8 R/W word
DO_pulseStatus 0: STOP, 1:
START
0016 01:COIL
STATUS
00017 8 R/W bit
DO_status 0: OFF, 1: ON 0000 01:COIL
STATUS
00001 8 R/W bit
DO-all_statusFromDO
-00
0: OFF, 1: ON 0032 03:HOLDIN
G
REGISTER
40033 1 R/W word

Moxa Technologies ioLogik E1212 Specifications

General

Cable type	AWG
Module type	Digital
Channel type	-
Signal direction	Input/output
Power consumption	130 mA
Dimensions (WxDxH)	27.8 x 84 x 124 mm
Output current range	0 - 0.2 A
Ethernet LAN (RJ-45) ports	2
Supported network protocols	Modbus/TCP, TCP/IP, UDP, DHCP, Bootp, HTTP
Isolation	3 kV
Channels quantity	16 channels
