Moxa Technologies ioLogik E1212 User Manual

5
5. Activating the EtherNet/IP Function
The ioLogik E1200 series will support the EtherNet/IP protocol after it has been registered and activated. In this
chapter, we explain how to activate the EtherNet/IP function in the ioLogik E1200 series. The EtherNet/IP
function can only be activated for firmware and utility versions that are the same as or more recent than those
listed below.
Firmware:
• ioLogik E1210 V2.5 (std. version)
• ioLogik E1211 V2.4 (std. version)
• ioLogik E1212 V2.5 (std. version)
• ioLogik E1213 V2.6 (std. version)
• ioLogik E1214 V2.5 (std. version)
• ioLogik E1240 V2.4 (std. version)
• ioLogik E1241 V2.5 (std. version)
• ioLogik E1242 V2.5 (std. version)
• ioLogik E1260 V2.5 (std. version)
• ioLogik E1262 V2.5 (std. version)
Utility:
• ioSearch V1.15 (std. version)

Moxa Technologies ioLogik E1212 Specifications

General

Cable type	AWG
Module type	Digital
Channel type	-
Signal direction	Input/output
Power consumption	130 mA
Dimensions (WxDxH)	27.8 x 84 x 124 mm
Output current range	0 - 0.2 A
Ethernet LAN (RJ-45) ports	2
Supported network protocols	Modbus/TCP, TCP/IP, UDP, DHCP, Bootp, HTTP
Isolation	3 kV
Channels quantity	16 channels
