Moxa Technologies ioLogik E1212 User Manual

3
3. Using the Web Console
The ioLogik E1200’s main configuration and management utility is the built-in web console, which can be used
to configure a wide range of options.
The following topics are covered in this chapter:

Introduction to the Web Console

Overview

Network Settings for the Web Console
 General Settings
 Ethernet Configuration

User-Defined Modbus Addressing
 Default Modbus Address

AOPC Server Settings
 Tag Generation

I/O Settings
 DI Channels
 DO Channels
 AI Channels
 AI Input Range
 AO Channels
 RTD Channels
 TC Channels

Peer-to-Peer Networking
 Peer-to-Peer Settings (1-50)
 Sample Peer-to-Peer Configuration
 DO Safe Mode Settings
 AO Safe Mode Settings

SNMP
 SNMP Trap
 Using SNMP
 Accessibility IP List

RESTful API Setting

EtherNet/IP Setting

System Management
 Network Connection
 Firmware Update
 Import System Configuration Settings
 Export System Settings

Change Password

Load Factory Defaults

Moxa Technologies ioLogik E1212 Specifications

General

Cable type	AWG
Module type	Digital
Channel type	-
Signal direction	Input/output
Power consumption	130 mA
Dimensions (WxDxH)	27.8 x 84 x 124 mm
Output current range	0 - 0.2 A
Ethernet LAN (RJ-45) ports	2
Supported network protocols	Modbus/TCP, TCP/IP, UDP, DHCP, Bootp, HTTP
Isolation	3 kV
Channels quantity	16 channels
