MiiNePort E2/E3 DIO Commands
D-3
Response
Byte # Descriptor Value Description
1 Header 1 command #, fixed
2 Header 2 version, fixed
3 Header 0, 1, 2, 3,
4, 5, 6,
0xFF
command status/error code (0 = okay)
4 Header 3 data length, fixed
5 Data 0, 1, 2, 3 desired DIO channel #
6 Data 0, 1 0: channel is in input mode
1: channel is in output mode
7 Data 0, 1 0: channel status is low
1: channel status is high
For example, the seven-byte response sequence 1-2-0-3-0-0-0 indicates that DIO 0 is in input mode.
C Code Example
BOOL ReadSingleDIO(int port, int *mode, int *status)
{
DIOPacketStruct packet;
packet.header.command = 1; // read single DIO command
packet.header.version = 2; // DIO protocol version
packet.header.length = 1; // data length
packet.data[0] = (char)port; // Number of the DIO
send(SocketFd, (char *)&packet, sizeof(DIOHeaderStruct)+1, 0);
//Send TCP Packet
// Process the returned data here.
return TRUE;
}
Write Single DIO
Command
Byte # Descriptor Value Description
1 Header 2 command number, fixed
2 Header 2 version, fixed
3 Header (any) this byte is only used in the module’s response
4 Header 3 data length, fixed
5 Data 0, 1, 2, 3 desired DIO channel number
6 Data 0, 1 0: set to input mode
1: set to output mode
7 Data 0, 1 this byte is ignored for input mode
0: set to low
1: set to high
For example, the seven-byte command sequence 2-2-0-3-0-0-0 requests that DIO 0 be set to digital input
mode.
