MiiNePort E2/E3 Introduction to SCM (Serial Command Mode) Command Set
A-42
Command Code for Viewing the Status
Ethernet Speed and Duplex
Command code: NS
Command parameters: N/A
Reply parameters: The speed and duplex status of the Ethernet. Possible values are 0(Unlink), 10H(10Mbps
Half Duplex), 10F(10Mbps Full Duplex), 100H(100Mbps Half Duplex), 100F(100Mbps Full Duplex).
?VNS
System requests current Ethernet status.
!VNS0100F
MiiNePort reports the Ethernet is current in 100Mbps Full Duplex mode.
DIO mode
Command code: PM
Command parameters: DIO port index and IO mode (0 for input and 1 for output), separated by semicolon (;).
For MiiNePort E2, the index is as following:
Index
DIO port
MiiNePort E2 PIN number
0 DIO 0 JP3 - PIN1
1 DIO 1 JP3 - PIN4
2 DIO 2 JP3 – PIN2
3 DIO 3 JP3 - PIN3
Note that this function works only if related PIN function is set to DIO.
Reply parameters: N/A
?VPM2
↲
System requests for DIO running mode of DIO port 2.
!VPM01
↲
MiiNePort reports DIO port is in output.
DIO state
Command code: PS
Command parameters: DIO port index and output state (0 for low and 1 for high).
Note that this function works only if DIO mode is set to output.
Reply parameters: N/A
?VPS2
↲
System requests for DIO state of DIO port 2.
!VPS01
↲
MiiNePort reports DIO port is in high state.
Control Command Code
PING
Command code: NP
Command parameters: Target host name or IP address.
Reply parameters: A single minus symbol indicates the target host did not reply in 1000 milliseconds.
Otherwise, one decimal number indicating the reply latency in milliseconds is returned.
?CNPwww.moxa.com
System requests to PING www.moxa.com.
!CNP010
Target host replies in 10 milliseconds.
?CNP192.168.1.1
System requests to PING 192.168.1.1.
!CNP0-
Target host did not reply in 1000 milliseconds.
