Moxa Technologies MiiNePort E2-H - Command;Reply Format

MiiNePort E2/E3 Introduction to SCM (Serial Command Mode) Command Set
A-2
Command/Reply Format
Single Line Command Format
Head Op Cmd Parameters Tail
1 byte 1 byte 2 bytes 0 to n bytes 1 or 2 bytes
Single Line Reply Format
Head Op Cmd Parameters Tail
1 byte 1 byte 2 bytes 0 to n bytes 1 or 2 bytes
Head and Tail
Head
1 byte
Tail
1 or 2 bytes
Command ?
CR
LF
CR-LF
Reply ! LF
Operation Code
Operation Code Meaning
G Get configuration from MiiNePort’s RAM
S Set configuration to MiiNePort’s RAM
R Retrieve running configuration
V View status
C Control
Status Codes
Status Code Meaning
E Enter Serial Command Mode
0 Command was executed successfully
1 Unrecognized format
2 Operation is not valid
3 Command is not valid
4 Parameter is incorrect
5 Parameter is too long
Restriction
The total number of parameters in a single command cannot exceed 1024 characters.
