MiiNePort E2/E3 Web Console Configuration
7-6
The MiiNePort will use the closest baudrate that is supported.
Data Bits
Setting Factory Default Necessity
5, 6, 7, 8 8 Required
Stop Bits
Setting Factory Default Necessity
1, 1.5, 2 1 Required
Stop Bits will be set to 1.5 when Data Bits is set to 5 bits.
Parity
Setting Factory Default Necessity
None, Even, Odd,
Space, Mark
None Required
Flow control
Setting Factory Default Necessity
None, RTS/CTS,
DTR/DSR, XON/XOFF
RTS/CTS Required
FIFO
Setting Factory Default Necessity
Enable, Disable Enable Required
Each module’s serial port provides a 128-byte FIFO both in the Tx and Rx directions. Disable the FIFO setting
when your serial device does not have a FIFO to prevent data loss during communication.
Interface
Setting Description Necessity
RS-232/422/485 RS-232, RS-422/485 Required
