6 Installation
Messko GmbH 202034 BA4001150/10 ENMSENSE
®
DGA 2/3
CAUTION
Risk of burns
Hot oil can push the device out of the ball valve and spray out.
► Ensure that the safety chain is correctly bolted in place and does not sag.
8. Position a collecting tray below the valve opening in the oil extraction
adapter and open the ball valve by aligning the lever up to the stop paral-
lel to the measuring pipe.
Figure19: Venting the device
9. Open any upstream valves and slides.
Excess air will be purged from the system via the oil extraction adapter due
to the pressure of the oil.
10. Vent the system until only oil flows out of the adapter.
