MSA M1 User Manual

Contents
1 Safety Regulations 5
1.1 Correct Use 5
1.2 Liability Information 5
2 Description 7
2.1 Scope of Delivery 7
2.2 Overview 7
2.3 Digital Clock 8
2.4 Status LEDs 8
2.5 Tally 9
2.6 Location Label 9
2.7 Telemetry System Overview 9
2.8 Setting Up the Telemetry System 10
2.9 Display Overview 10
3 Before Use 13
3.1 Charging the Device 13
3.2 Setting Up the Clocks 13
3.2.1 Setting up the ECB Clock 13
3.2.2 Setting Up the Tablet Clock via Designated Menu Items 14
3.3 Pre-Setup: Connection to the Telemetry System 14
3.3.1 Connecting to a Network with a Single MSA HUB 15
3.3.2 Connecting to a Network with more MSA HUBs 17
4 Use 19
4.1 Turning On/Off 19
4.2 Synchronizing the Manual and Tablet Clock 19
4.3 Connecting the Entry Control Board to MSA HUB 19
4.4 Creating a New Entry Control Point 22
4.5 Connecting to an Entry Control Point 24
4.6 Configuring Settings 25
4.6.1 Switching into Dark Mode 26
4.6.2 Changing the Time Display 27
4.6.3 Changing the WiFi Network 28
4.6.4 App Information 29
4.6.5 Contact Support 30
4.6.6 Setting Pressure Thresholds 30
4.7 Logging On the First BA Wearer 30
4.8 Logging On Additional BA Wearers 33
4.8.1 Assigning to an Existing Team 33
4.8.2 Assigning to a New Team 34
4.8.3 Adding BA Wearers Manually 35
4.9 Using Repeaters 36
4.10 Evacuation 36
4.10.1 Initiating a Single Team Evacuation 37
4.10.2 Initiating a Collective Evacuation 40
4.10.3 Incident States 42
4.11 Alarms/Warnings 44
5 After Use 48
5.1 Logging Off a BA Wearer 48
3
GB

MSA M1 Specifications

General

Type	Control Unit
Input Voltage	24 VDC
Operating Temperature	-20°C to +60°C
Protection Rating	IP65
Dimensions	150 x 100 x 50 mm
Weight	0.5 kg
