MSA M1 User Manual

11 Technical Data
Dimensions L x W x H (housing) 510 mm x 440 mm x 65 mm
Weight 4200 g
Ambient temperature range -18 °C to +58 °C
Storage temperature range -18 °C to +58 °C
Humidity 10 to 90 % r.H. (non-condensing)
Power dissipation Peak max: 15 W
Power supply Minimum input voltage: 110 V DC
Maximum input voltage: 230 V DC
Connectivity LAN: 1x RJ-45
WLAN: 802.11 a/b/g/n/ac
2.4G + 5.8G Dual Band Wi-Fi
Bluetooth: 4.2 (BLE) Class 1.5
GPS: U-blox NEO-7
WWAN: Integrated LTE module
NFC: 13,56 MHz support:
ISO 14443A/14443B/15693/18092/Mifare
64
GB 11 Technical Data

MSA M1 Specifications

General

Type	Control Unit
Input Voltage	24 VDC
Operating Temperature	-20°C to +60°C
Protection Rating	IP65
Dimensions	150 x 100 x 50 mm
Weight	0.5 kg
