The status "On Withdrawal" is set by long pressing one of the green buttons on
the M1 Control Module (see M1 Control Module Operating Manual).
The BA wearer is on retreat.
If a user does not set withdrawal state prior to withdrawal alarm the M1 Control
Module shows withdrawal alarm and the Entry Control Board changes to active
“Withdrawal Alarm”.
43
4 Use GB
