NS50 wireless network switch

User Manual

Revision C

Chapter 3: Installation

Commercial in Confidence

IMPORTANT: Protect all connectors and sockets from dust and grit, with minimal

exposure during installation. Any unused sockets must be covered by the supplied

dust caps at all times during installation. Any unused sockets must be covered by

the supplied dust caps at all times.

Step

Procedure

Illustration

Loosen the thumbscrew on the retention

arm.

Slide out the retention arm from the NS50.

Push down on the locking catch for the port

and remove the cover.
