HYDROCAL 1001+ Installation and operation manual Page 15/76
Communication connection:
The Ethernet communication is either connected via copper wire (RJ45) or fibre optical (SC Du-
plex) (must be specified when ordering).
Copper wire:
Recommendation for Ethernet communication cable (copper):
Cable type: Ethernet cable Cat. 5e with RJ45 connector
Cable diameter : 6,3 mm
Fibre optical:
Recommendation for Ethernet communication cable (fibre optical):
Cable type: HITRONIC
®
HQN 1000 Multimode G4 62,5/125 with SC Duplex connector
Cable diameter : 6,5 mm
Bending radius: min. 15 x Ø
RS485 interface:
Recommendation for RS485 interface communication cable:
Cable type: UNITRONIC
®
BUS LD FD P cable 1x2x0.25 mm
2
, shielded, purple
Cable diameter : 6,2 mm
Alarm- and analog outputs:
Recommendation for alarm and analog outputs cable:
Cable type: ÖLFLEX
®
FD855CP (or equivalent)
Cable diameter : 13,3 mm
Cross section : 0,5 mm
2
(of 16 internal wires)
2.4.3. Putting into operation
When the supply voltage for the unit is switched on, a short beep is hearable and after a short time
the LEDs of the internal and external user interface shows the specified conditions confirming that
the HYDROCAL unit is working correctly (4).
After successful initialization, you can remount the protection cover and fasten it with the
knurled thumb screw.
The measurement cycles are performed every 20 minutes and are synchronized on the clock
mark; this means the first measurement values are available approx. 2, 22 or 42 min. after the
clock mark.
To check the heating function, touch carefully the back plate after some minutes.
