Note: The standard settings for gas concentration absolute alarm (High-High) are:
 Level 1: 500 Level 2: 1000
 Delay 1 [s]: 7200 or 2:00:00 Delay 2 [s]: 43200 or 12:00:00
 Action 1: Output,Hold Action 2: Output,Hold
Note: The standard settings for gas concentration daily trend alarm (High-High) are:
 Level 1: 50 Level 2: 100
 Delay 1 [s]: 43200 or 12:00:00 Delay 2 [s]: 86400 or 1-0:00:00
 Action 1: Output,Hold Action 2: Output,Hold
Note: The standard settings for gas concentration weekly trend alarm (High-High) are:
 Level 1: 100 Level 2: 200
 Delay 1 [s]: 86400 or 1-0:00:00 Delay 2 [s]: 172800 or 2-0:00:00
 Action 1: Output,Hold Action 2: Output,Hold
These settings can be modified in Hydrosoft -> alarm setup.
4.2.3. Moisture LED
The HYDROCAL unit contains also an alarm level monitoring for the moisture concentration, which is
assigned to the moisture LED and the relay output 3 (connection terminal X2:5&6).
The multicolor LED illustrates the status of the alarm level for moisture concentration as follow:
Description
Alarm level monitoring not active
No Alarm
- not defined -
Moisture concentration - level 1 (High) alarm is triggered
Note: The standard settings for moisture concentration alarm (High) are:
 Level 1: 10
 Delay 1 [s]: 7200 or 2:00:00
 Action 1: Output,Hold
These settings can be modified in Hydrosoft -> Alarm setup.
