HYDROCAL 1001+ Installation and operation manual Page 52/76
II - LEDs of internal user interface and digital relay outputs
h’
Relay output 4 (X2:7/8)
   i
with Jumper J1 on Pos. 1 (J1:1-2)
h’’
Relay output 4 (X2:7/8)
   i
with Jumper J1 on Pos. 2 (J1:2-3)
i
Relay output 1 (X2:1/2)
   j
j
Relay output 2 (X2:3/4)
   k
k
Relay output 3 (X2:5/6)
   l
III - LEDs of internal- and external user interface
All LEDs - ON
l
Internal user interface External user interface
 m
All LEDs - OFF
m
Internal user interface External user interface
 End
IV - Return to normal operation
Note: After this sequence all present alarms will be automatically acknowledged.
