134 Part Number STH034 3/12
WATER DISPENSE SOLENOID VALVE
Function
Opens and closes to control water flow.
Specifications
24 VDC
Check Procedure
CONTINUAL WATER FLOW
1. Place power switch in off position
• Flow continues - Replace valve
• Flow stops - Replace relay board
NO WATER FLOW
1. Verify water is supplied.
2. Energize the water valve.
3. Check for line voltage at valve coil:
• Line voltage present - Replace water valve
• Line voltage not present - Replace relay board.
