176 Part Number STH034 3/12
Water and Refrigeration Circuit Version 1
Ice Machine R404A Refrigerant
RESERVOIR
WATER
INLET
CONTROL
WATER
VALVE
FLOAT
SWITCH
OVERFLOW
WATER LEVEL
EVAPORATOR
DRIER
SPOUT
EXPANSION
VALVE
GEAR
MOTOR
FLUSH
WATER
VALVE
CONDENSER
FAN MOTOR
CONDENSER
COMPRESSOR
DRAIN PAN
WATER CIRCIUT
PRESSURE
SWITCH
REFRIGERANT CIRCUIT
