Part Number STH034 3/12 151
Temperature/Resistance Chart
This chart is used for the temperature control
thermistors. As the temperature rises at the thermistor
block, the resistance drops.
If the ohmmeter reads “OL,” check the scale setting on
the meter before assuming the thermistor is bad.
°C °F OHM
-17.8 0 43,297
-15.0 5 36,503
-12.2 10 30,884
-9.4 15 26,948
-6.7 20 22,928
-3.9 25 20,082
-1.1 30 17,188
1.7 35 14,751
4.4 40 13,019
7.2 45 11,506
10.0 50 9,951
