Manual# I27028 5-8 Rev. 2 – 11/22/2017
Figure 5-5
DETAILED REACTIVATION TEMPERATURE INFO
Here are the items on this screen:
SETPOINT Setpoint for reactivation outlet temperature
PVr Current reactivation inlet or outlet temperature
CV "Control Variable" - percentage of full reactivation heat output.
Although the temperatures may be displayed in °F or °C, the factory default is °F. To return
to the Machine Running display, press the BACK button, followed by the MAIN button.
These values have been set in the factory and should not be changed.
2. HMI - CHECKING THE SYSTEM AND DH RUN TIME
The System and DH run time are displayed on the Machine Running screen. See Figure
below.
Figure 5-6
CHECKING SYSTEM AND DH RUN TIME
