Technical Data
User manual 57106_hdb_en_13 20 / 94
5 Technical Data
Hardware and software ver-
sion
Cube20S PROFIBUS DP bus node Art.-No.57101
Hardware version 04
Firmware version V1.5.7
Power supply
Supply voltage (nominal value) 24 V
Supply voltage (admissible range) 20.4...28.8 V
Reverse-polarity protection Yes
Power consumption (idle) 95 mA
Power consumption (nominal value) 0.95 A
Switch-on current 3.9 A
I
2
t 0.14 A
2
s
Current supply on the backplane bus 3 A
Current supply load supply 10 A
Power dissipation 3 W
Status, alarm, diagnostics
Status indication Yes
Alarms Yes, configurable
Process interrupt Yes, configurable
Diagnostic interrupt Yes, configurable
Diagnostic function Yes, configurable
Diagnostic information can be read out possible
Supply voltage indication Green LED
Maintenance indication Yellow LED
Collective error indication Red LED
Channel error display None
Design
Max. racks 1
Assemblies in each rack 64
Max. no. of digital assembly groups 64
Max. no. of analog assembly groups 64
Communication
Fieldbus PROFINET IO
Physics Ethernet 100 MBit
Connection 2 x RJ45
Topology
electrically isolated yes
Max. no. of devices
Device address
Min. transfer rate 100 Mbit/s
Max. transfer rate 100 Mbit/s
Max. address range for inputs 512 bytes
Max. address range for outputs 512 bytes
Max. no. of TxPDO
Max. no. of RxPDO
