General data
User manual 57106_hdb_en_13 18 / 94
4 General data
Conformity
CE 2014/30/EU EMC Directive
2011/65/EU RoHS
Certifications
Certification according to UL Yes
Certification according to KC Yes
Personal and device protection
Degree of protection EN 60529 IP20
Electrical isolation
To fieldbus - Galvanically decoupled
To process level - Galvanically decoupled
Insulation resistance EN 61131-2 -
Insulation voltage to reference ground
Inputs / outputs - 50 V / ,
at a test voltage of 500 V
Protective measures - against short circuit
Ambient conditions
Climatic
Storage / transport EN 60068-2-14 -25 ... +70 °C
Operation
Horizontal installation, sus-
pended
EN 61131-2 0 ... +60 °C
Horizontal installation, lying EN 61131-2 0 .... +55 °C
Vertical installation EN 61131-2 0 ... +50 °C
Air humidity EN 60068-2-30 RH1 (without condensation,
relative humidity 10 … 95
%)
Pollution EN 61131-2 Degree of pollution 2
Installation height Above sea level 2000 m
Mechanical
vibration EN 60068-2-6 1 g, 9 Hz ... 150 Hz
Shock EN 60068-2-27 15 g, 11 ms
Mounting conditions
Installation site - Inside the switch cabinet
Installation position - Horizontal and vertical
Fastening - 35 mm DIN rail
