6.2.1 Functional principle of the locking

Inserting and locking the module

 The terminal module has a locking lever at its top.

1 | For installation and disassembly, please press this locking lever upwards

until it engages audibly.

2 | Plug the module to be mounted in the previously plugged-in module.

3 | Slide the module with the help of the guide strips at top and bottom onto

the DIN rail.

4 | Flap the locking lever downwards.

The module is fastened to the DIN rail.
