Configuration/settings
User manual 55170_hdb_en_13 52 / 145
IO-Link master The IO-Link master has 2 IO-Link ports that can be allocated specific IO-Link
devices or can be set in SIO mode.
 Read and write access to the IO-Link devices/ports.
Tab. 8-6: Submodules for IO-Link master
Submodules
Deactivated  The corresponding IO-Link port is disabled, i.e., the
channel is neither used as a digital input or output, nor
as an IO-Link port.
IOL_I/O_SI 0 bytes In, 0 bytes Out
 IO-Link standard IO mode.
 The channel is addressed as digital input.
The data are read via "Digital IO".
IOL_I_x Byte x bytes In
 IO link device with x byte(s) input data.
 The status can be identified via the corresponding bit
in "Qualifier DI".
 It is possible to modify the diagnostics and IO link
properties.
IOL_O_y Byte y bytes Out
 IO link device with y byte(s) output data.
 The status can be identified via the corresponding bit
in "Qualifier DO".
 It is possible to modify the diagnostics and IO link
properties.
IOL_I/O_x/y Byte x bytes In, y bytes Out
 IO link device with x byte(s) input data and y byte(s)
output data.
 The status can be identified via the corresponding bit
in "Qualifier DI" and "Qualifier DO".
 It is possible to modify the diagnostics and IO link
properties.
