Page #56 background imageLoading...
Page #56 background image
Configuration/settings
User manual 55170_hdb_en_13 56 / 145
8.2 Module parameterization
This chapter explains parameterization options.
8.2.1 Module parameters
Tab. 8-9: Module parameters
Parameters Description
1 Report / do not report global diagnostics Enables / Disables all diagnostics of the module.
If these diagnostics are disabled, the settings of parameters 2,
4, 6 and 7 are then ignored.
2 Report / do not report
undervoltage bus/sensor supply
Enables / disables the report about undervoltage of the
bus/sensor supply.
3 Threshold value for undervoltage bus/sensor
supply
Defines the threshold value for detection of undervoltage in
bus/sensor power supply.
Default value
16.8 ... 17.3 V
4 Report / do not report
undervoltage actuator supply
Enables / Disables the report about undervoltage of the actua-
tor supply.
5 Undervoltage actuator supply threshold value Defines the threshold value for detection of undervoltage in the
actuator supply.
Default value
16.8 ... 17.3 V
6 Report / do not report
power failure in the actuator supply
Enables / Disables the report about lack of actuator supply.
7 LED indication for suppressed diagnostics Enables / Disables LED indication for suppressed diagnostics.
8 Murrelektronik IO-Link tool Enables / Disables the use of the Murrelektronik
IO-Link device configuration tool.
9 Pin/Port-based Transmission of IO data in pin- or port-based format.
10 Input delay The input delay acts as a filter that only recognizes input sig-
nals as high at the active time X.
