Installation
User manual 55170_hdb_en_13 42 / 145
6.1.2 Connecting the Ethernet bus
Connecting the
M12 port
Fig. 6-2: Example of M12 connection (Ethernet bus)
M12 0,6 Nm
Art.-No.
7000-99102-0000000
