Installation
User manual 55170_hdb_en_13 41 / 145
Sensor supply Please note:
Sensors can be supplied via pin 1 (24 V) and pin 3 (0 V) of the M12 female
connectors.
The maximum permissible current for the power supply of the sensors is
0.2 A for the digital I/O port and 1.0 A for the IO-Link port.
In case of overcurrent or short circuit, the connected cable or sensor must
be disconnected from the M12 female connector.
Supported IO-Link
communication
The module supports the IO-Link communication using the following speeds:
4,800 baud (COM 1)
38,400 baud (COM 2)
230,400 baud (COM 3)
NOTE
The cable length is limited to 20 m. The IMPACT67 automatically selects the
communication speed suitable for the IO-Link device.
You will find a wide range of connecting wires in the catalog or in the online
shop of Murrelektronik GmbH at: http://shop.murrelektronik.com
