Technical Data
User manual 55170_hdb_en_13 28 / 145
4 Technical Data
4.1 Electrical data
Bus data
Fieldbus protocol PROFINET
PROFINET Conformance Class C
Transfer rate 100 Mbit/s
PROFINET adressing Via DCP
Cycle time ≥1 ms
IRT Network communication Yes
Application No
MRP Client Yes
PROFIenergy V1.2
FSU (Fast-start-up) ≤500 ms
Shared Device/Input yes, for 2 controllers
PROFINET Netload Class III
Supply
Operating voltage US 24 V
Voltage range US 18 ... 30 V
When using IO-Link 20,3 ... 30 V
Operating voltage UA 24 V
Voltage range UA 18 ... 30 V
Sensor current US ≤40 °C (see Derating) ≤16 A
Actuator current UA ≤40 °C (see Derating) ≤16 A
Current consumption At idle ≤0,18 A
Cross section of M12L connector ≤1,5 mm
2
Protection against reverse polarization
for US and UA
Yes
Reverse polarity protection Yes
Galvanic isolation No
Input (DI)
Filter time 1 ms
Delay time for signal change 2 ... 5 ms
Input characteristic EN 61131-2, type 3
Sensor power supply slot DIO ≤0,2 A Last
Automatic start
Short-circuit protection, sensor supply High-side switch with
overload protection
Connection M12
Conductor cross-section M12 ≤0,75 mm
2
Output (DO)
Output current slot DIO ≤1,6 A per channel
Total current outputs ≤40 °C (see Derating) ≤9 A
Frequency ≤50 Hz
Short-circuit protection actuator High-side switch with
overload protection
Connection/ports M12
Conductor cross-section ≤0,75 mm
2
