Mounting
User manual 55170_hdb_en_13 37 / 145
5.4.1 Functional ground
With grounding strap
NOTE
Use a conductive screw to attach the ground strap.
Fig. 5-4: Grounding strap fastening
Without grounding
strap
NOTE
Remove the grounding strap and secure the module to the metal substrate
with a conducting screw.
Fig. 5-5: Grounding directly to metal substrate
M4 1,2 Nm
Art.-No.
7000-98001-0000000
M6 3 Nm
Art.-No.
7000-98001-0000000
