Configuration/settings
User manual 55170_hdb_en_13 105 / 145
8.7 Media redundancy (MRP) configuration
MRP The procedure regarding the configuration of media redundancy is described
in the engineering software manual.
In this document, a configuration example is described using the Siemens TIA
Portal engineering software.
Preparatory steps:
1 | Set up a project in the TIA portal.
2 | Add a controller and a PROFINET Managed Switch.
3 | Add the IMPACT67 module.
4 | Assign the IMPACT67 module to the controller
(see Fig. 8-36: "Setting up the MPR manager").
