Mounting
User manual 55170_hdb_en_13 34 / 145
5.3 Mounting distance
Fig. 5-2: Distance in mm
NOTICE
For correct installation and improved heat dissipation, we recommend
keeping a minimum distance of 3 mm when mounting the IMPACT67.
NOTE
When using angled connectors, a minimum distance of 50 mm to the wall,
ceiling and between the modules must be kept.
