Configuration/settings
User manual 55170_hdb_en_13 55 / 145
State  Reading access to the digital IOs only.
 Access to the system status
Tab. 8-8: Submodules for state
Further information on diagnostic messages to IO-Link ports can be found in
the 9.2.3 "Diagnostic messages at IO-Link ports"
Submodules
Parameter/Diagnostic Parameterization of the module
 Diagnostic behavior
 Data layout
Digital IO 4 bytes In
 Bytes 0 and 1
 Value of the inputs as individual bits.
 Layout according to parameter settings
 Bytes 2 and 3
 Currently configured value of the outputs as indi-
vidual bits.
 Layout according to parameter settings
Qualifier DI 2 bytes In
 Status of individual bits of the inputs in "Digital IO"
 0: invalid
 1: valid
 Layout according to parameter settings
Qualifier DO 2 bytes In
 Status of individual bits of the outputs in "Digital IO"
 0: invalid
 1: valid
 Layout according to parameter settings
System state 4 bytes In
 Summary of the current system status.
Further information can be found in the Tab. 8-19:
"System state IO layout".
