Configuration/settings
User manual 55170_hdb_en_13 64 / 145
LED indication for sup-
pressed diagnostics
Fig. 8-11: LED indication for suppressed diagnostics
The LED indication for suppressed diagnostics defines
whether disabled diagnostics should still use LEDs for indicating purpos-
es.
Tab. 8-14: LED indication for suppressed diagnostics
Selection Meaning
D = Default
No LED indication D Disables the diagnostics using the correspond-
ing parameter --> this is followed by no signal
via the LEDs.
LED indication Disable the diagnostics via the corresponding
parameters --> there is a signal via the LEDs.
