Configuration/settings
User manual 55170_hdb_en_13 73 / 145
Diagnostics IO-Link
port
Fig. 8-17: Diagnostics IO-Link port
Diagnostics to be reported
Tab. 8-20: Diagnostics IO-Link port
Selection Meaning
D = Default
Report all diagnostics D The module will report all diagnostics. This
means all IO-Link port diagnostics and all IO-
Link device diagnostics.
Report all diagnostics except for line
break
The module will report all diagnostics, except for
line break. This means that all IO-Link port diag-
nostics will be reported except for line break and
all IO-Link device diagnostics.
Report only line break diagnostics The module will only report the line break IO-
Link port diagnostic.
Report no diagnostics The module will report no diagnostics. This
means that no IO-Link port diagnostics and no
IO-Link device diagnostics will be reported.
