Configuration/settings
User manual 55170_hdb_en_13 75 / 145
According to IO-Link integration guideline Edition 1
This type of illustration only provides rudimentary diagnostic options be-
cause several different IO-Link event codes are depicted on the same
PROFINET Channel Error Type.
The PROFINET Channel Error Type therefore only occasionally permits a
conclusion to be drawn about the original IO-Link event code.
"Error"-type IO-Link events are reported as PROFINET diagnostics with
"Fault" maintenance.
IO-Link events of the "Warning" type are reported with "Maintenance de-
manded".
IO-Link events of the "Notification" type are not reported as PROFINET di-
agnostics but are instead handled as "Notifications from the device" pa-
rameterization.
The diagnostics do not include any channel numbers.
NOTICE
The illustration and overview of the IO-Link event codes on PROFINET diag-
nostics can be found in chapter 9.2.3.1 "According to IO-Link integration
guideline Edition 1" .
