Installation ValueCut USER MANUAL
30
VC2E-A-00
2.7 Cutting Pad Installation
1 piece of cutting pad is included in the accessory pack. Follow the instruction below to install a new
cutting pad when the existing pad is worn out.
Step 1
Carefully remove the cutting pad from the unit.
Step 2
Remove the remaining adhesive on the groove with alcohol or cleaning naphtha.
Remaining adhesive
Remaining adhesive
Figure 2-24
Figure 2-25
