4 All technical manuals are available in PDF format at tech.napcosecurity.com Napco iSecure Security System
INTRODUCTION
NAPCO's iSecure Security System is an easy to install, state
-of-the-art microcomputer-based burgla-
ry alarm system with integral cellular
communicator. Installation allows for
wall mounting or placement on a table
top. iSecure supports up to 80 wireless
protection zones that may be divided
into 1 or 2 Areas, each containing their
own protection zones. The basic system
can be easily expanded, with all Kits
compatible with the following standard
devices:
• IBR-TOUCH-WL Smart 7" Wireless
IoT Touchscreen Keypad
• ISEC-WL-TOUCH Wireless 4.3" Full Color Security
Touchscreen Keypad
• ISEC-WL-KEYPAD Wireless Battery-Powered Standard
Keypad
• ISEC-WL-SIREN Wireless Siren
• ISEC-WL-MODULE Wireless 8-Zone Takeover Module
• ISEC-DW-XMITTER Low Profile Window/Door Transmitter
• ISEC-KEYFOB 4-Button Pendant/Keychain Transmitter
• ISEC-SMOKE Supervised Wireless Digital Smoke Sensor
• ISEC-MOTION Passive Infrared Motion Sensor
• ISEC-GLASSBREAK Wireless Glass-Break Sensor
• ISEC-CARBON MON Supervised Wireless Carbon
Monoxide Sensor
• ISEC-PANIC Single Button Waterproof Panic
• ISEC-HEAT Wireless Heat Detector with Rate of Rise
• ISEC-ZWAVE Z-Wave Module
• ISEC-WIFI Internet Module
• ISEC-2WF-MOD 2-Wire Fire Sensor Module
• SLE-EXTANT-KIT Adapter Cable for ANTEXT Kits:
• SLE-ANTEXT30 30' Remote Antenna Kit
• SLE-ANTEXT50 50' Remote Antenna Kit
• SLE-ANTEXT75 75' Remote Antenna Kit
• SLE-ANTEXT100 100' Remote Antenna Kit
See page 73 for ordering and additional information. Re-
fer to our website for the latest revisions of the documentation
FEATURES
• iPhone and Android phone apps allow for local and remote
arm / disarm, system status and Z-Wave control
• Cloud-based programming in the iSecure Cloud Web
Portal (www.iSecureByNapco.com)
• Integral 319MHz wireless receiver allows for compatibility
with all NAPCO 319MHz wireless transmitters
• Integral 4-wire bus terminals that support the GEMWV-
RECV (additional peripherals require power supply)
• Integral Ethernet 10/100 network connection for central sta-
tion communication, notifications and IBR-TOUCH-WL op-
eration
• Integral Hub siren with Burg, Fire and CO Alarm cadences
capable of 85dBA at 10 feet (Note: The Hub's integral siren
only activates upon an Area 1 alarm. All other external si-
rens activate upon an alarm in any Area.)
• Integral voice prompts with 4 volume levels
• Hub enclosure tamper available (WI2382LF Hub tamper in-
stallation instructions included)
• All Kits support up to six (6) ISEC-WL-KEYPADs and/or
ISEC-WL-TOUCHs, combined. When the Go-Anywhere
Hub is connected to a network with a Wi-Fi access point, up
to four (4) IBR-TOUCH-WL tablet keypads can be used.
• Powered by 16.5VAC transformer (included). Provision for
rechargeable 4AH or 5AH 12V backup battery (not supplied)
that automatically provides power during AC power outages
• System fully monitors AC power and charges the backup
battery
• LTE cellular radio module for wireless central station com-
munication, notifications, remote programming and firmware
downloads
• Integral supervised bell output
• Integral PGM output initiated by a keyfob button press
(toggle on/off or momentary on for 5 seconds)
• 900MHz Wireless Transceiver Module for adding other wire-
less system peripherals, including the ISEC-WL-KEYPAD,
the ISEC-WL-TOUCH Touchscreen, the ISEC-WL-MODULE
Takeover Module and the ISEC-WL-SIREN.
• Optional ISEC-ZWAVE Z-Wave Module for programming/
control of Z-Wave home automation controls such as Z-
Wave-enabled lights, outlets, thermostats, garage door oper-
ators and door locks
• Optional ISEC-WIFI Internet Module for central station com-
munication and notifications (supplied in KIT 3; see page 73
for kit ordering information).
• Optional SLE-ANTEXT30 / 50 / 75 / 100 Extended Range
Remote Indoor/Outdoor Antenna to increase LTE cellular
transmission signal strength (see WI2230 for instructions)
• Optional ISEC-2WF-MOD 2-Wire Fire Sensor Module that
supports 2 Fire zones (connect to Fire Power [+], Zone 7 [‒]
and Zone 8 [‒] terminals)
See page 73 for ordering and additional information.
Note: Not all pages in this manual apply to all systems. Use
the instructions for the peripherals and devices included with
the iSecure kit or for any additional devices purchased, as re-
quired. All wireless devices, including Z-Wave devices,
must be signal tested with all enclosure covers fully
closed, including the Go-Anywhere Hub.
Note: iSecure, Gemini Wave (GEMWV) and Gemini (GEM)
transmitters are compatible with the iSecure system; however,
iSecure and Gemini Wave (GEMWV) transmitters are not com-
patible with Gemini GEM-Receivers.
PROGRAMMING
To simplify the installation process, the Go-Anywhere Hub can
be programmed either through the programming screens in the
iSecure phone app or by accessing the same programming
screens in the iSecure Cloud Web Portal
(www.iSecureByNapco.com). In addition, a log containing up
to 800 events monitors Go-Anywhere Hub activity referenced
to a precision real-time clock. This detailed event history may
be displayed in the website page or in the app, as needed.
Overview
Go-Anywhere Hub
™
