NAPCO iSecure User Manual

Napco iSecure Security System All technical manuals are available in PDF format at tech.napcosecurity.com 77
ISEC-WL-SIREN Wireless Siren Mounting Template
Slide Screw
(Use with battery
powered units
only)
Magnet
1-5/8"
7/16"
Magnet Screws (2)
(Use with battery
powered units only)
"Center Line of
Wall Socket"
5-1/4"
Screw Hole Tab
Align this centerline
with Wall Socket
This template shows the
unit plugged into the
bottom receptacle, but
either can be used (or
invert the unit as re-
quired).
Remove the two screws
from the siren housing
and replace screws with
bracket in place, as
shown.
ENSURE THIS
BOX IS
1 INCH
X
1 INCH
For Wall Outlets
Without a Center
Cover Plate Screw

NAPCO iSecure Specifications

General

Brand	NAPCO
Model	iSecure
Category	Security System
Language	English
