Napoleon Ascent Linear Series Installation Manual

W415-2757 / B / 01.09.20
EN
58
replacement parts
Items may not appear exactly as illustrated.
Ref. No.
Part Number Description
Stocked Ref. No.
Part Number Description
Stocked
20
44
11
25
2012 2013 20 14 20 15 20 16 20 17 20 18 2020 2021 20 22
4427 4424
2023
4426
2019
26 27
Yes Yes
W725-0062 886 Proflame valve (NG) W725-0063 886 Proflame valve(P)
20
W175-0217 Flex connector w/ valve Yes
W245-0025 Thermosensor
12 12
W456-0043 Burner orifice #43 (NG) Yes
13
W456-0053 Burner Orifice #53 (P) Yes
14 15 16 16
Yes
17
Yes Yes Yes
18
W335-0039
Pilot hood
W455-0070
Pilot orifice #62 (NG)
W455-0068 Pilot orifice #35 (P) W720-0062 Pilot tube (w/ fittings) W240-0013
Electrode (w/ wire)
Yes
19
W290-0355 Valve train gasket
W290-0157 Manifold gasket
11
W432-0103
Manifold flex pipe
24 24 25
W010-2763 Pilot assembly (NG) W010-2808 Pilot assembly (P)
W750-0270 Wire switch
21 22 23
W190-0176 Control board W750-0267 Wire harness (control) W350-0702 Battery back-up
Yes Yes
26
28
29
W750-0294
W175-0633
W100-0223-SER Burner assembly
4428
4429
Power cord wire (18”) Connector w/ flags
13.4 BL46 valve train assembly

Napoleon Ascent Linear Series Specifications

General

Model	Ascent Linear Series
Category	Indoor Fireplace
Fuel Type	Natural Gas or Propane
Viewing Area	Varies by model
Ignition System	Electronic Ignition
Control System	Remote Control
Glass Type	Tempered Glass
Vent Type	Direct Vent
Burner Type	Linear Burner
Dimensions	Varies by model
Weight	Varies by model
Installation Type	Built-in
Log Set	Optional
Warranty	Limited Lifetime Warranty
