6.6 Keybed and Light Guide
The Light Guide visualizes the key mapping of loaded Instruments and sample mapping. By
color coding sample based Instruments and indicating active and inactive keys in scales using
the LEDs above the keybed. The Smart Play settings are also reflected by the Light Guide. This
means that when you select e.g. a scale or chord, the LEDs corresponding to the keys con-
tained in that scale or chord will light up, whereas inactive keys remain unlit. The Light Guide
also gives you visual feedback when you play back incoming MIDI note patterns from the host.
The Light Guide
Keyboard Overview
Keybed and Light Guide
KOMPLETE KONTROL - Manual - 52
