◦ Resolution: Adjusts the sensitivity of the control element to your actions. At high Res-
olution values, a little movement of the control element will be enough to trigger the
message. At lower Resolution values, you will have to move it more frankly to trigger
the message.
▪ Relative (Offset): This mode is similar to the Relative mode explained above, with the differ-
ence that here the values sent for the “+1” and “-1” messages are 65 and 63, respectively
— in other terms, they are centered around 64 instead of 0. This is well suited for some
particular software implementations. As in Relative mode, a Step parameter defines the in-
crement to use, and a Resolution parameter adjusts the sensitivity of the control element
to your actions.
8.4.6 Assignments for Buttons
For the Buttons, the Type menu offers the entries Control Change, Program Change, and Note.
Depending on the selected entry, the further available options differ subsequently. The follow-
ing table details the different combinations of options:
Type Menu Value Mode Menu Value Value Number Note
Control Change Toggle Off / On
(0-127)
Number
(0-127)
Trigger 0 - 127
Program Change Toggle Off / On
(0-127)
Trigger 0 - 127
Note Toggle Off / On
(0-127)
Note C-2 – G8
Trigger 0 - 127
MIDI Communication
Using the MIDI Assignment Editor
KOMPLETE KONTROL - Manual - 94
