Nicolet Systems
1-8 April 27, 2015
Separating the headbox from the Nicolet EEGwireless32/64 amplifier
1. Press downward on the release latch (Figure 1).
2. While firmly holding the Nicolet EEGwireless32/64 amplifier and headbox, pull
the headbox towards yourself.
3. Carefully lift off the Nicolet EEGwireless32/64 amplifier from the headbox.
Figure 1
Headbox interchangeability
You cannot use a 64 channel headbox with a 32 channel amplifier, but you can use a
32 channel headbox with a 64 channel amplifier.
NOTE: Montage setups between 32 channel configurations and 64 channel
configurations are not interchangeable.
1
2
