Nautel FM10 - Ref des Index - NAPD05;01 A Control;Display PWB

10 000 WATT FM BROADCAST TRANSMITTER
FM10
Page 8-16
15 November 1999
Table 8-6 Ref Des Index - NAPD05/01A Control/Display PWB
USE REF NAME OF PART NAUTEL'S JAN/MIL/OEM X/Y OEM
CODE DES AND DESCRIPTION PART NO. PART NO. GRID CODE
- Control/Display PWB NAPD05/01A 182-4044-02 - 37338
CR1 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 D/4 27014
CR2 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 E/4 27014
CR3 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 E/4 27014
CR4 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 E/4 27014
CR5 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 E/4 27014
CR6 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 E/4 27014
CR7 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 F/4 27014
CR8 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 F/4 27014
CR9 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 F/4 27014
CR10 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 F/4 27014
CR11 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 F/4 27014
CR12 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 G/4 27014
CR13 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 G/4 27014
CR14 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 D/4 27014
CR15 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 D/4 27014
CR16 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 D/4 27014
CR17 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 D/2 27014
CR18 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 E/2 27014
CR19 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 E/2 27014
CR20 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 E/2 27014
CR21 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 E/2 27014
CR22 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 E/2 27014
CR23 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 F/2 27014
CR24 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 F/2 27014
CR25 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 F/2 27014
CR26 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 F/2 27014
CR27 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 F/2 27014
CR28 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 G/2 27014
CR29 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 G/2 27014
DS1 Diode, Light Emitting, Red QK13 HLMP-3351 G/12 50434
DS2 Diode, Light Emitting, Red QK13 HLMP-3351 F/12 50434
DS3 Diode, Light Emitting, Red QK13 HLMP-3351 D/12 50434
DS4 Diode, Light Emitting, Red QK13 HLMP-3351 C/12 50434
DS5 Diode, Light Emitting, Red QK13 HLMP-3351 H/12 50434
DS6 Diode, Light Emitting, Red QK13 HLMP-3351 D/13 50434
DS7 Diode, Light Emitting, Red QK13 HLMP-3351 C/13 50434
DS8 Diode, Light Emitting, Red QK13 HLMP-3351 B/13 50434
DS9 Diode, Light Emitting, Red QK13 HLMP-3351 E/12 50434
DS10 Diode, Light Emitting, Red QK13 HLMP-3351 H/13 50434
DS11 Diode, Light Emitting, Red QK13 HLMP-3351 G/13 50434
DS12 Diode, Light Emitting, Red QK13 HLMP-3351 F/13 50434
DS13 Diode, Light Emitting, Red QK13 HLMP-3351 E/13 50434
DS14 Diode, Light Emitting, Amber QK14 HLMP-3451 G/2 50434
DS15 Diode, Light Emitting, Green QK12 HLMP-3554 B/2 50434
J1 Connector, Header, 50 pin, Ribbon Cable 161-3007-50 161-3007-50 H/3 37338
J2 Header, MTA, 4 Square Posts, 0.156 Centre JU20 640383-4 I/12 09482
