10 000 WATT FM BROADCAST TRANSMITTER
FM10
Page 8-27
15 November 1999
Table 8-13 Ref Des Index - NAPC60/03 3-Phase Monitor PWB
USE REF NAME OF PART NAUTEL'S JAN/MIL/OEM X/Y OEM
CODE DES AND DESCRIPTION PART NO. PART NO. GRID CODE
- 3-Phase Monitor PWB NAPC60/03 166-7026-03 - 37338
C1 Capacitor, Tantalum, 6.8uF 10% 35V CCP19 CSR13F685KM 56289
C2 Capacitor, Ceramic, 0.1uF 10% 100V CCG07 CKR06BX104KRV 56289
C3 Capacitor, Tantalum, 22uF 10% 35V CCP20 CSR13F226KM 56289
CR1 Diode, General Purpose, 600V, 1A QM31 1N4005 04713
CR2 Diode, General Purpose, 600V, 1A QM31 1N4005 04713
CR3 Diode, General Purpose, 600V, 1A QM31 1N4005 04713
CR4 Diode, General Purpose, 600V, 1A QM31 1N4005 04713
CR5 Diode, General Purpose, 600V, 1A QM31 1N4005 04713
CR6 Diode, General Purpose, 600V, 1A QM31 1N4005 04713
CR7 Diode, General Purpose, 600V, 1A QM31 1N4005 04713
CR8 Diode, General Purpose, 600V, 1A QM31 1N4005 04713
CR9 Diode, General Purpose, 600V, 1A QM31 1N4005 04713
CR10 Diode, General Purpose, 600V, 1A QM31 1N4005 04713
CR11 Diode, General Purpose, 600V, 1A QM31 1N4005 04713
CR12 Diode, General Purpose, 600V, 1A QM31 1N4005 04713
CR13 Diode, Zener, 12V, 400mW, 5% QG08 1N759A 04713
CR14 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 27014
CR15 Diode, General Purpose, 200V, 0.1A QAP29 1N4938 27014
DS1 Not Used -
F1 Fuse, 1A, 125V, Fast, PICO II FC09 251001 75915
F2 Fuse, 1A, 125V, Fast, PICO II FC09 251001 75915
F3 Fuse, 1A, 125V, Fast, PICO II FC09 251001 75915
J1 Header, MTA, 4 Square Posts, 0.156 Centre JU20 640383-4 09482
J2 Header, MTA, 8 Square Posts, 0.156 Centre JU08 640383-8 09482
K1 Relay, 12VDC Coil, 2PDT, 1A KC07 DF2E-DC12V 61529
Q1 Transistor, NPN, General Purpose QAP04 2N2219A 04713
R1 Not Used
R2 Not Used
R3 Not Used
R4 Resistor, Metal Film, 1.0M Ohms, 1% 1/4W RAC13 MF55D1004F 59124
R5 Resistor, Metal Film, 1.0M Ohms, 1% 1/4W RAC13 MF55D1004F 59124
R6 Resistor, Metal Film, 1.0M Ohms, 1% 1/4W RAC13 MF55D1004F 59124
R7 Resistor, Metal Film, 825 Ohms, 1% 1/4W RAB24 MF55D8250F 59124
R8 Resistor, Metal Film, 825 Ohms, 1% 1/4W RAB24 MF55D8250F 59124
R9 Resistor, Metal Film, 332K Ohms, 1% 1/4W RAC07 MF55D3323F 59124
R10 Resistor, Metal Film, 100K Ohms, 1% 1/4W RAC01 MF55D1003F 59124
R11 Resistor, Metal Film, 100K Ohms, 1% 1/4W RAC01 MF55D1003F 59124
R12 Resistor, Variable, Film, 100K Ohms, 1/2W RW01 3339P-1-104 80294
R13 Resistor, Metal Film, 2.21M Ohms, 1% 1/4W RAC17 MF55D2214F 59124
R14 Resistor, Metal Film, 4750 Ohms, 1% 1/4W RAB33 MF55D4751F 59124
R15 Resistor, Metal Film, 4750 Ohms, 1% 1/4W RAB33 MF55D4751F 59124
R16 Resistor, Metal Film, 18.2K Ohms, 1% 1/4W RAB40 MF55D1822F 59124
R17 Resistor, Metal Film, 681K Ohms, 1% 1/4W RAC11 MF55D6813F 59124
R18 Resistor, Metal Film, 100K Ohms, 1% 1/4W RAC01 MF55D1003F 59124
R19 Resistor, Metal Film, 22.1K Ohms, 1% 1/4W RAB41 MF55D2212F 59124
R20 Resistor, Metal Film, 10K Ohms, 1% 1/4W RAB37 MF55D1002F 59124
