Nautel FM10 - Ref des Index - NAFP64 10 Kw RF Power Probe

10 000 WATT FM BROADCAST TRANSMITTER
FM10
Page 8-22
15 November 1999
Table 8-10 Ref Des Index - NAFP64 10kW RF Power Probe
USE REF NAME OF PART NAUTEL'S JAN/MIL/OEM OEM
CODE DES AND DESCRIPTION PART NO. PART NO. CODE
- RF Power Probe, 10kW NAFP64 182-6005 37338
A1 Forward Power Probe PWB 161-6069-02 161-6069-02 37338
A1C1 Capacitor, Ceramic, 0.001uF 10% 200V CCG01 CKR05BX102KRV 56289
A1CR1 Diode, Hot Carrier QK09 1N5711 50434
A1R1 Resistor, Metal Film, 100 Ohms, 5% 2W RBP07 GS-3, 100 Ohms 75042
A1R2 Not Used
A2 Reflected Power Probe PWB 182-6040 182-6040 37338
A2C1 Capacitor, Ceramic, 0.001uF 10% 200V CCG01 CKR05BX102KRV 56289
A2CR1 Diode, Hot Carrier QK09 1N5711 50434
A2R1 Not Used
A2R2 Resistor, Variable, Film, 500 Ohms, 1/2W RW36 3339P-1-501 80294
A2R3 Resistor, Metal Film, 3300 Ohms, 2% 1/2W RAP11 RL20S332G 35005
A3 RF Monitor Probe PWB 182-6040-01 182-6040-01 37338
A3C1 Not Used
A3CR1 Not Used
A3R1 Resistor, Metal Film, 100 Ohms, 5% 2W RBP07 GS-3, 100 Ohms 75042
A3R2 Not Used -
A3R3 Resistor, Metal Film, 47 Ohms, 5% 2W RBP05 GS-3, 47 Ohms 75042
J1
Connector, Coaxial, BNC, 50Ù, Bulkhead
JDP26 UG1094/U 02660
J2
Connector, Coaxial, BNC, 50Ù, Bulkhead
JDP26 UG1094/U 02660
J3
Connector, Coaxial, BNC, 50Ù, Bulkhead
JDP26 UG1094/U 02660
J4 Connector, Output Cup (3 1/8 inch EIA ) 182-6045 182-6045
NOTE
: Partial reference designation shown. Prefix with A25 (ref des of all higher assemblies) to
obtain complete reference designation.
