10 000 WATT FM BROADCAST TRANSMITTER
FM10
Page 8-23
15 November 1999
Table 8-11 Ref Des Index - NAS43/02 Low Voltage Power Supply
USE REF NAME OF PART NAUTEL'S JAN/MIL/OEM OEM
CODE DES AND DESCRIPTION PART NO. PART NO. CODE
- Low Voltage Power Supply NAS43/02 182-7040-02 37338
- Low Voltage Power Supply NAS43/02A 182-7040-05 37338
A1 Low Voltage Power Supply PWB NAPS09C/01 See Table 8-12 37338
A2 3-Phase Monitor PWB NAPC60/03 See Table 8-13 37338
C1 Capacitor, Electrolytic, 7100uF, 60V CBP06 3188BC712U060AMA1 56699
C2 Capacitor, Ceramic, 0.1uF 10% 100V CCG07 CKR06BX104KRV 56289
F1 Fuse, 10A, 250V, Slow, 3AB FB35 326010 75915
F2 Fuse, 10A, 250V, Slow, 3AB FB35 326010 75915
F3 Fuse, 10A, 250V, Slow, 3AB FB35 326010 75915
F4 Fuse, 1A, 250V, Slow, 3AG FA08 313001 75915
F5 Fuse, 1A, 250V, Slow, 3AG FA08 313001 75915
P1 Connector, MTA, Closed End, 12-Pin, 22AWG JU03 1-640433-2 09482
P2 Connector, MTA, Closed End, 4-Pin, 22AWG JU01 640433-4 09482
Q1 Not Used
Q2 Not Used
Q3 Transistor, Field Effect, N Channel QAP38 IRFP140 81483
Q4 Transistor, Field Effect, N Channel QAP38 IRFP140 81483
Q5 Transistor, Field Effect, N Channel QAP38 IRFP140 81483
Q6 Thyristor, 25A, 800V QS12 2N6509 04713
TB1 Terminal Block, 6 Single Terminals, FT, 15A JB07 14306 13150
TP1 Jack, Tip, White JN16 105-0201-200 74970
TP2 Jack, Tip, White JN16 105-0201-200 74970
TP3 Jack, Tip, White JN16 105-0201-200 74970
TP4 Jack, Tip, White JN16 105-0201-200 74970
TP5 Jack, Tip, White JN16 105-0201-200 74970
U1 Bridge Rectifier, 400V, 35A UM21 36MT40A 81483
U2 Voltage Regulator, Adjustable, Neg Volts, 3A UT35 LM333T 27014
U3 Voltage Regulator, Adjustable, Pos Volts, 3A UT36 LM350T 27014
U4 Voltage Regulator, Adjustable, Pos Volts, 3A UT36 LM350T 27014
XF1 Fuseholder, Panel, Type 3AG Fuse BAP30 342012A 75915
XF2 Fuseholder, Panel, Type 3AG Fuse BAP30 342012A 75915
XF3 Fuseholder, Panel, Type 3AG Fuse BAP30 342012A 75915
XF4 Fuseholder, Panel, Type 3AG Fuse BAP30 342012A 75915
XF5 Fuseholder, Panel, Type 3AG Fuse BAP30 342012A 75915
NOTE
: Partial reference designation shown. Prefix with A26 (ref des of all higher assemblies) to
obtain complete reference designation.
NAS43/02 and NAS43/02A variations are electrically identical.
