5-10 BenchMike Pro 2025/2050 & Z-Mike Pro 4025/4050 Instruction Handbook: Advanced Capabilities
5.4 Using a Footswitch
A footswitch can be used to trigger a BenchMike Pro function without touching the BenchMike Pro itself. Connect
the DB-25 connector of the footswitch to the DB-25 plug on the rear of the BenchMike Pro labelled DIGITAL I/O.
The footswitch should be connected between pin 2 and pin 12 on this connector. All pins are defined in the Digital
I/O Connector section.
