BenchMike Pro 2025/2050 & Z-Mike Pro 4025/4050 Instruction Handbook: Remote Setup 6-9
Measure Data <MEAS DATA>
Measure Data is either the actual measurement data specified by the .MEAS.FORMAT command or is an error
message. The error messages are:
NO SCAN!♪◙
GATE OBSCURED! ♪◙
MISSING! ♪◙
EXTRA! ♪◙
EXCESSIVE FILTERING! ♪◙
100% FLAWS! ♪◙
LOW POWER! ♪◙
No further messages are sent until the error condition is cleared.
6.2.5 Prefix Setting
Some PURL commands are quite long. To speed command entry you can set a temporary command prefix. The
prefix is automatically prepended to subsequent commands issued to the BenchMike Pro. You create a prefix by
typing a partial command followed by a period. When a prefix is set, the BenchMike Pro responds with "PREFIX
SET". To clear a prefix just send an extra CR. The BenchMike Pro will respond with "PREFIX CLEARED".
For example, to issue the commands:
CONF.SCANNER.FEAT.SEL:1♪
CONF.SCANNER.FEAT.INSERT♪
CONF.SCANNER.FEAT.MEAS.LOWERREF:ON♪
CONF.SCANNER.FEAT.MEAS.UPPERREF:ON♪
you can enter the following:
CONF.SCANNER.FEAT. ♪ (setting prefix to CONF.SCANNER.FEAT.)
SEL:1♪
INSERT♪
MEAS. ♪ (setting prefix to CONF.SCANNER.FEAT.MEAS.)
LOWERREF:ON♪
UPPERREF:ON♪
