BenchMike Pro 2025/2050 & Z-Mike Pro 4025/4050 Instruction Handbook: Remote Setup 6-11
6.3.1.3 Configuring the Digital Port: CONF.DIG
The following table lists the options for configuring the optional digital input and output.
NOTE: The CONF.DIG.INPUT.SWITCH.SEL command should be used to select the desired switch before any
MODE commands are issued.
NOTE: The CONF.DIG.OUTPUT.ALARM.SWITCH.SEL command should be used to select the desired switch
before any MODE commands are issued.
CONF.DIG.INPUT.
SWITCH.MODE
Request or specify the mode and function of a digital input.
Both mode and function must be specified after the semi-
colon. Possible modes are OFF (disable), TOG (toggle), NO
(normally open), and NC (normally closed). Possible functions
are OFF, GO/STOP, CLEAR_DATA, CLEAR_LAST, PRINT, SEND,
CLEAR_LATCHED, FLOATING_NOMINAL , ADVANCE_FEATURE,
BACKUP_FEATURE, EMERGENCY_STOP, and ZERO_FIXTURE. Ex-
amples:
CONF.DIG.INPUT.SWITCH.MODE:OFF GO/STOP
CONF.DIG.INPUT.SWITCH.MODE:TOG GO/STOP
CONF.DIG.INPUT.SWITCH.MODE:NO CLEAR_LAST
CONF.DIG.INPUT.SWITCH.MODE:NC PRINT
CONF.DIG.INPUT.SWITCH.MODE?
CONF.DIG.INPUT.
SWITCH.SEL
Select a digital input number for setup and/or query. This val-
ue can be between 1 and 8. Examples:
CONF.DIG.INPUT.SWITCH.SEL:1
CONF.DIG.INPUT.SWITCH.SEL?
CONF.DIG.OUTPUT.
ALARM.SWITCH.MODE
Request or specify the mode event to trigger the selected
alarm output. First, the setting for the output must be de-
fined. Options are: NO (normally open), and NC (normally
closed). Second, the alarm can be NOT_LATCHED or LATCHED.
There are several possible options for the mode event (the
third input for this command). These are: REJECT_HIGH,
WARNING_HIGH, WARNING_LOW, REJECT_LOW, GOOD, and
END_OF_PART. Examples:
CONF.DIG.OUTPUT.ALARM.SWITCH.MODE:NO LATCHED REJECT_HIGH
CONF.DIG.OUTPUT.ALARM.SWITCH.MODE: NC NOT_LATCHED
END_OF_PART
CONF.DIG.OUTPUT.ALARM.SWITCH.MODE?
CONF.DIG.OUTPUT.
ALARM.SWITCH.SEL
Request or specify the currently active alarm output. Exam-
ples:
CONF.DIG.OUTPUT.ALARM.SWITCH.SEL:1
CONF.DIG.OUTPUT.ALARM.SWITCH.SEL?
