NEC iPasolink 200 - Unpacking Procedures for IDU and ODU

UNPACKING of IDU and ODU 3-1
Installation NWD-107460-02E
3. UNPACKING of IDU and ODU
The unpacking procedures for the IDU and ODU are shown in following chart.
IDU: Procedure 3-1
ODU: Procedure 3-2
Note When conveying the IDU or ODU to another place, the original packing
should be used to avoid damage.
Procedure 3-1 Unpacking Method for IDU
1 Open the top cover of the packing box.
Packing label
Recycle Mark
Care Mark
