NEC iPasolink 200 User Manual

2-5 PACKAGES
NWD-107460-02E Installation
Fig. 2-4 Installation Kit Packing List of IDU and ODU for 1+1 System
PS-S
SFP Module
Connector
D-Sub Connector
(Female)
MDR Connector
Power Supply
Connector
FAN Unit
(Replaceable)
16E1-S
D-Sub Connector
MDR Connector
Power Supply Connector
AUX-S
STM1-S
SFP Module Connector
ODU (13-38 GHz)
N-P Connector
ODU (6-11 GHz)
ODU (13-38 GHz)
N-P Connector
TNCP
Connector
USB Connector
Modular
Connector
ODU (6-11 GHz)
Lug (FG)
TNCP Connector
N-P Connector
N-P Connector
Lug (FG)
Lug (FG)
Lug (FG)
Lug (FG)
